The Registrations page of the UCx Web Portal displays all of your static and dynamic registrations.
To view your current registrations:
- Log in to the UCx Web Portal at ucx.telepacific.com.
- Click Utilities on the left-hand menu.
- On the Utilities page, click the Registrations link.
- The Registrations page opens and displays your current settings.
- When finished, click OK to return to the Utilities menu.
The following table explains the key fields on this page:
|Endpoint Type||The SIP device or virtual user endpoint at which the service is deployed. Valid types include Primary, Video Add On, and Shared Call Appearance.|
|Line/Port||The line, port number or SIP address of the endpoint location. This information is dependent on the identity/device profile’s type.|
|Identity/Device Profile Name||Your assigned Identity/Device Profile in the system.|
|URI||The Universal Resource Indicator (URI) identifying the device. Both static and dynamic registrations are possible, depending on the device profile.|
|Expiration||The registration expiry date, for dynamic registrations.|
|Lockout Started||If your device has been locked out due to a SIP authentication failure, the lockout start time is displayed.|
|Lockout Expires||For a temporary lockout, this is the time when the lockout expires.|
|Lockout Count||If your device has been temporarily locked out, this is the number of temporary lockouts. If the lockout is permanent, Permanent is displayed here.|
